Intel
INTG INTEL WI-FI 7 BE202 2230 2x2 BE+BT No vPro
Pre-Order
€23.99
VAT (19%) included
Description
Wireless M.2 WLAN / Bluetooth 2400 Mbit/s Wi-Fi Tri-band (2.4 GHz / 5 GHz / 6 GHz) Bluetooth 5.4 Internal Component for: PC/Laptop
Technical Specifications
SKU
KBE202.NGWG.NV
Connectivity Technology
Wireless
Host Interface
M.2
Interface
WLAN / Bluetooth
Maximum Data Transfer Rate
2400 Mbit/s
Networking Standards
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11az, IEEE 802.11b, IEEE 802.11be, IEEE 802.11d, IEEE 802.11e, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11u, IEEE 802.11v, IEEE 802.11w
Wi-Fi Band
Tri-band (2.4 GHz / 5 GHz / 6 GHz)
Top Wi-Fi Standard
Wi-Fi 7 (802.11be)
Wi-Fi Standards
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
Security Algorithms
AES-CCMP, AES-GCMP, EAP-AKA, EAP-SIM, EAP-TLS, EAP-TTLS, MSCHAPv2, PEAP, WPA2, WPA3
Bluetooth Version
5.4
Component For
PC/Laptop
Antenna Type
2x2
Windows Operating Systems Supported
Windows 10, Windows 11
Operating Temperature (T-T)
0 - 80 °C
Width
22 mm
Depth
30 mm
Height
2.4 mm
Weight
3.07 g
Compliance Certificates
CB, UL
Harmonized System (Hs) Code
8517620090
Launch Date
Q3'23
Status
Launched
Ethernet Adapter Ark Id
234444
Export Control Classification Number (Eccn)
5A992C
Commodity Classification Automated Tracking System (Ccats)
740.17B1
