STARTECH.COM USB 2.0 auf Seriell Adapter - USB zu RS422 / 485 Industrie Schnittstellen-Konverter mit Isolation - Wandmontagefh
Pre-Order
€168.99
VAT (19%) included
Description
Provides one RS422/485 port while powering the device through USB RS-485 mode supports Auto Transceiver Turn Around (ATTA) Compatible with both USB 2.0 and USB 1.1 RS422/485 Baud rate up to 921.6 Kbps Supports DB9 and terminal block connector Optical Isolation and Surge Protection (2500 Vrms) Supports 4-wire RS422 and 2-wire RS485 applications
Technical Specifications
SKU
KICUSB422IS
Connector 1
USB B
Connector 2
RS-422/485
Connector 1 Gender
Male
Connector 2 Gender
Female
Cable Length
1.8 m
Product Colour
Black
Data Transfer Rate
0.00088 Gbit/s
Compatible Operating Systems
Windows CE (4.2, 5.0, 6.0), XP Embedded, 98SE, 2000, XP, Vista, 7, 8, 8.1, 10, 11 Windows Server 2003, 2008 R2, 2012, 2012 R2, 2016, 2019 macOS 10.6 to 10.15, 11.0, 12.0, 13.0 Linux Kernel 3.0.x+
Input Voltage
5 V
Operating Temperature (T-T)
0 - 55 °C
Storage Temperature (T-T)
-20 - 85 °C
Relative Humidity
5 - 95%
Width
64 mm
Depth
118 mm
Height
23 mm
Weight
180 g
Quantity Per Pack
1 pc(s)
Cables Included
USB
Package Width
145 mm
Package Depth
209 mm
Package Height
42 mm
Package Weight
390 g
Products Per Master (Outer) Case
50 pc(s)
Master (Outer) Case Width
412 mm
Master (Outer) Case Length
426 mm
Master (Outer) Case Height
278 mm
