Connectivity Technology
Wireless
Maximum Data Transfer Rate
600 Mbit/s
Networking Standards
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ac
Wi-Fi Band
Dual-band (2.4 GHz / 5 GHz)
Frequency Range
2.4 - 5 GHz
Top Wi-Fi Standard
Wi-Fi 5 (802.11ac)
Wi-Fi Standards
802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Wlan Data Transfer Rates Supported
11, 54, 150, 433, 600 Mbit/s
Modulation
16-QAM, 256-QAM, 64-QAM, CCK, DBPSK, DQPSK, OFDM
Security Algorithms
128-bit WEP, 64-bit WEP, 802.1x RADIUS, WPA, WPA2, WPA2-AES, WPA2-PSK, WPA2-TKIP, WPS
Receiver Sensitivity
5GHz: 11a 6Mbps: -94dBm 11a 54Mbps: -78dBm 11n HT20 MCS0: -94dBm 11n HT20 MCS7: -77dBm 11n HT40 MCS0: -92dBm 11n HT40 MCS7: -74dBm 11ac VHT80 MCS0: -89dBm 11ac VHT80 MCS9: -64dBm 2.4GHz: 11b 1Mbps: -99dBm 11b 11Mbps: -91dBm 11g 6Mbps: -94dBm 11g 54Mbps: -77dBm 11n HT20 MCS0: -95dBm 11n HT20 MCS7: -76dBm 11n HT40 MCS0: -92dBm 11n HT40 MCS7: -73dBm
Windows Operating Systems Supported
Windows 10, Windows 7, Windows 8, Windows 8.1, Windows XP
Mac Operating Systems Supported
macOS
Operating Temperature (T-T)
0 - 40 °C
Storage Temperature (T-T)
-40 - 70 °C
Operating Relative Humidity (H-H)
10 - 90%
Storage Relative Humidity (H-H)
5 - 90%
Quantity Per Pack
1 pc(s)
Compliance Certificates
RoHS
Harmonized System (Hs) Code
85176990
