Thermaltake
700W Thermaltake TR2 S | ErP ready
Pre-Order
€67.99
VAT (19%) included
Description
700 W 230 V 50 - 60 Hz Motherboard power connector: 20+4 pin ATX PC ATX 80 PLUS Active 12 cm 1800 Black
Technical Specifications
SKU
KPS-TRS-0700NPCWEU-2
Total Power
700 W
Ac Input Voltage
230 V
Ac Input Frequency
50 - 60 Hz
Input Current
9 A
Power Factor Correction (Pfc) Type
Active
Combined Power (+3.3V)
120 W
Combined Power (+12V)
648 W
Combined Power (+5V)
120 W
Combined Power (-12V)
6 W
Combined Power (+5Vsb)
12.5 W
Max Output Current (+3.3V)
24 A
Max Output Current (+12V)
54 A
Max Output Current (+5V)
17 A
Max Output Current (-12V)
0.5 A
Max Output Current (+5Vsb)
2.5 A
Hold Time
16 ms
Efficiency
86%
Motherboard Power Connector
20+4 pin ATX
Number Of Sata Power Connectors
6
Peripheral (Molex) Power Connectors (4-Pin)
5
Pci Express Power Connectors (6+2 Pin)
2
Cabling Type
Non-Modular
80 Plus Certification
80 PLUS
Purpose
PC
Power Supply Unit (Psu) Form Factor
ATX
Atx Version
2.3
Mean Time Between Failures (Mtbf)
100000 h
Product Colour
Black
Cooling Type
Active
Fan Diameter
12 cm
Number Of Fans
1 fan(s)
Fan Speed
1800
Fan Location
Top
Operating Temperature (T-T)
5 - 40 °C
Storage Temperature (T-T)
-40 - 55 °C
Operating Relative Humidity (H-H)
20 - 85%
Storage Relative Humidity (H-H)
10 - 95%
Certification
CE/CB/TUV
Width
150 mm
Depth
140 mm
Height
86 mm
Package Type
Box
Harmonized System (Hs) Code
84733020
