LC-Power
400W LC-Power Office LC500-12 | 80+Bronze
Pre-Order
Usually ready in 3-5 business days
+ €30 Supplier Shipping
€42.99
VAT (19%) included
Description
350 W 230 V 50 Hz Motherboard power connector: 20+4 pin ATX PC ATX 80 PLUS Bronze 12 cm Grey
Technical Specifications
SKU
KLC500-12 V2.31
Total Power
350 W
Peak Power
400 W
Ac Input Voltage
230 V
Ac Input Frequency
50 Hz
Input Current
3 A
Maximum Input Current (@110V)
+12V1,+12V2,+3.3V,+5V,+5Vsb,-12V
Power Factor Correction (Pfc) Type
Active
Combined Power (+3.3V)
103 W
Combined Power (+12V)
300 W
Combined Power (+5V)
103 W
Combined Power (-12V)
6 W
Combined Power (+5Vsb)
12.5 W
Max Output Current (+3.3V)
21 A
Max Output Current (+12V1)
11 A
Max Output Current (+12V2)
14 A
Max Output Current (+5V)
15 A
Max Output Current (-12V)
0.5 A
Max Output Current (+5Vsb)
2.5 A
Efficiency
88.63%
Power Protection Features
Over power, Over voltage, Short circuit, Under voltage
Motherboard Power Connector
20+4 pin ATX
Number Of Sata Power Connectors
4
Number Of Pata Power Connectors
2
Pci Express Power Connectors (6-Pin)
1
Floppy Drive Power Connector
1
Cabling Type
Non-Modular
80 Plus Certification
80 PLUS Bronze
Purpose
PC
Power Supply Unit (Psu) Form Factor
ATX
Atx Version
2.31
Product Colour
Grey
Fan Diameter
12 cm
Number Of Fans
1 fan(s)
Certification
TÜV, CE
Width
150 mm
Depth
140 mm
Height
85 mm
Weight
1.38 kg
Package Type
Box
Harmonized System (Hs) Code
84733020
