ASUS
750W ASUS Netzteil ATS-750G BULK 80+ Gold
Pre-Order
€137.99
VAT (19%) included
Description
Dual ball fan bearings that can last up to twice as long as sleeve bearing designs. An 80 Plus Gold Certification is the result of low-ESR electrolytic capacitors and other premium components. Etched cables can be bent easily during installation.
Technical Specifications
SKU
K90YE04A1-B0NC00
Total Power
750 W
Ac Input Voltage
110 - 240 V
Power Factor Correction (Pfc) Type
Active
Combined Power (+3.3V)
100 W
Combined Power (+12V)
750 W
Combined Power (+5V)
100 W
Combined Power (-12V)
3.6 W
Combined Power (+5Vsb)
15 W
Max Output Current (+3.3V)
20 A
Max Output Current (+12V)
62.5 A
Max Output Current (+5V)
20 A
Max Output Current (-12V)
0.3 A
Max Output Current (+5Vsb)
3 A
Efficiency
92%
Power Protection Features
Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
Motherboard Power Connector
20+4 pin ATX
Motherboard Power Cable Length
55 cm
Number Of Sata Power Connectors
3
Peripheral (Molex) Power Connectors (4-Pin)
3
Pci Express Power Connectors (6+2 Pin)
2
Pci Express Power Cable Length
67.5 cm
Cpu Power Cable Length
65 cm
Cabling Type
Fully-Modular
80 Plus Certification
80 PLUS Gold
Purpose
PC
Power Supply Unit (Psu) Form Factor
ATX
Bearing Technology
Ball bearing
Mean Time Between Failures (Mtbf)
120000 h
Product Colour
Black
Cooling Type
Active
Number Of Fans
1 fan(s)
Cables Included
AC, PCIe, SATA
Packaging Content
Power Cord x 1 Motherboard Power Cable x 1 (550mm) CPU 1-to-2 Cable x 1 (650+100mm) PCI-E 1-to-2 Cable x 1 (675+100mm) SATA 1-to-3 Cable x 1 (400+120+120mm) Peripheral 1-to-3 Cable x 3 (400+120+120mm) Chassis Screws Package x 1 Quick Start Guide x 1
Compliance Certificates
RoHS
Width
150 mm
Depth
140 mm
Height
86 mm
Weight
1.53 kg
Package Width
250 mm
Package Depth
180 mm
Package Height
115 mm
Package Weight
2.78 kg
Package Type
Box
