NZXT
750W NZXT Netzteil 750W 80+ Bronze C Series ATX 2.53 PA-7B2BB-EU
Pre-Order
€89.99
VAT (19%) included
Description
Up to 88% efficiency at 50% load exceeds 80 Plus Bronze standards, reducing energy waste and heat A 120mm fluid dynamic bearing fan delivers low-noise performance with enhanced longevity DC-to-DC conversion ensures consistent power delivery to GPUs up to 220W, such as the RTX 3070 Tested for safety at up to 40°C, and features over-temperature and over-current protections Main PSU cables are nylon-sleeved for durability with a matte black finish to match any build
Technical Specifications
SKU
KPA-7B2BB-EU
Total Power
750 W
Ac Input Voltage
115 - 240 V
Ac Input Frequency
50/60 Hz
Input Current
10 - 5 A
Maximum Input Current (@110V)
10 A
Maximum Input Current (@220V)
5 A
Combined Power (+3.3V)
120 W
Combined Power (+12V)
750 W
Combined Power (+5V)
120 W
Combined Power (-12V)
3.6 W
Combined Power (+5Vsb)
12.5 W
Max Output Current (+3.3V)
20 A
Max Output Current (+12V)
62.5 A
Max Output Current (+5V)
20 A
Max Output Current (-12V)
0.3 A
Max Output Current (+5Vsb)
12.5 A
Efficiency
88.97%
Motherboard Power Connector
24-pin ATX
Motherboard Power Cable Length
60 cm
Sata Power Cable Length
150, 500 mm
Peripheral (Molex) Power Connectors (4-Pin)
4
Peripheral (Molex) Power Cable Length
150, 500 mm
Cabling Type
Non-Modular
80 Plus Certification
80 PLUS Bronze
Supported Motherboard Form Factors
ATX
Purpose
PC
Power Supply Unit (Psu) Form Factor
ATX
Atx Version
2.53
Eps Version
2.92
Noise Level
39.92 dB
Bearing Technology
FDB
Mean Time Between Failures (Mtbf)
100000 h
Product Colour
Black
Cooling Type
Active
Fan Diameter
12 cm
Number Of Fans
1 fan(s)
Fan Speed
2160 - 2640 RPM
Operating Temperature (T-T)
0 - 40 °C
Compliance Certificates
CE, Federal Communications Commission (FCC), RCM, RoHS, UKCA, WEEE
Width
150 mm
Depth
180 mm
Height
86 mm
Sustainable Technologies And Materials
Steel, PCB, plastic
Warranty Period
3 year(s)
