NZXT
850W NZXT Netzteil 80+ Gold C850 Vollmodular ATX 3.1
Pre-Order
€115.99
VAT (19%) included
Description
GPU Power: 12V-2x6 (PCIe 5.1) or triple 8-pin PCIe Efficiency Rating: 80 PLUS Gold, Cybenetics Platinum Noise Rating: Cybenetics A++ (<15 dBA) Fan Control: Zero RPM Mode
Technical Specifications
SKU
KPA-8G3BB-EU
Total Power
850 W
Ac Input Voltage
100 - 240 V
Ac Input Frequency
50/60 Hz
Input Current
10 - 5 A
Power Factor Correction (Pfc) Type
Active
Combined Power (+3.3V)
120 W
Combined Power (+12V)
850 W
Combined Power (+5V)
120 W
Combined Power (+5Vsb)
15 W
Max Output Current (+3.3V)
20 A
Max Output Current (+12V)
70.8 A
Max Output Current (+5V)
20 A
Max Output Current (+5Vsb)
3 A
Efficiency
89.33%
Power Protection Features
Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
Motherboard Power Connector
24-pin ATX
Motherboard Power Cable Length
60 cm
Number Of Sata Power Connectors
8
Sata Power Cable Length
100, 500 mm
Peripheral (Molex) Power Connectors (4-Pin)
3
Peripheral (Molex) Power Cable Length
100, 500 mm
Pci Express Power Connectors (6+2 Pin)
3
Pci Express Power Connectors (12+4 Pin)
1
Pci Express Power Connectors (12+4 Pin) Cable Length
650 mm
Cpu Power Cable Length
70 cm
Cabling Type
Fully-Modular
80 Plus Certification
80 PLUS Gold
Supported Motherboard Form Factors
ATX
Purpose
PC
Power Supply Unit (Psu) Form Factor
ATX
Atx Version
3.1
Eps Version
2.92
Noise Level
40.5 dB
Bearing Technology
FDB
Mean Time Between Failures (Mtbf)
100000 h
Product Colour
Black
Cooling Type
Active
Fan Diameter
13.5 cm
Number Of Fans
1 fan(s)
Fan Speed
0 - 2300 RPM
Operating Temperature (T-T)
0 - 50 °C
Cables Included
AC, CPU, PCIe, Peripheral (Molex), SATA
Certification
CE UKCA FCC IC BSMI CB (IEC 62368-1 Ed. 3) RCM KC
Width
150 mm
Depth
150 mm
Height
86 mm
Package Type
Box
