Thermaltake
850W Thermaltake Toughpower GF3 Gold ARGB Gen5
Pre-Order
€175.99
VAT (19%) included
Description
Toughpower GF3 ARGB series is fully compatible with Intel’s ATX 3.0 specification. Designed with a native PCIe Gen 5.0 connector, it can power up next-gen technology with one new 12VHPWR cable. The build-in 16.8M colors RGB fan and addressable RGB lighting synchronization with mainstream motherboards There are 8 colors in “Full Lighted” mode RGB Fan: 16.8M colors RGB ARGB control button: 8 lighting modes and a plenty of color options
Technical Specifications
SKU
KPS-TPD-0850F4FAGE-1
Total Power
850 W
Ac Input Voltage
100 - 240 V
Ac Input Frequency
50 - 60 Hz
Input Current
15 A
Power Factor Correction (Pfc) Type
Active
Combined Power (+3.3V)
100 W
Combined Power (+12V)
850 W
Combined Power (+5V)
100 W
Combined Power (-12V)
3.6 W
Combined Power (+5Vsb)
15 W
Max Output Current (+3.3V)
20 A
Max Output Current (+12V)
70.8 A
Max Output Current (+5V)
20 A
Max Output Current (-12V)
0.3 A
Max Output Current (+5Vsb)
3 A
Hold Time
17 ms
Efficiency
100%
Power Protection Features
Over current, Over power, Over voltage, Overheating, Short circuit, Under power
Motherboard Power Connector
24-pin ATX
Motherboard Power Cable Length
60 cm
Number Of Sata Power Connectors
12
Sata Power Cable Length
150, 500 mm
Peripheral (Molex) Power Connectors (4-Pin)
4
Peripheral (Molex) Power Cable Length
150, 500 mm
Pci Express Power Connectors (6+2 Pin)
4
Pci Express Power Connectors (16-Pin)
1
Pci Express Power Cable Length
60 cm
Cpu Power Cable Length
65 cm
Floppy Drive Power Connector
1
Floppy Disk Drive Cable Length
15 cm
Cabling Type
Fully-Modular
80 Plus Certification
80 PLUS Gold
Supported Motherboard Form Factors
ATX, micro ATX, Mini-ATX
Purpose
PC/Server
Power Supply Unit (Psu) Form Factor
ATX
Atx Version
3.0
Noise Level
33.5 dB
Bearing Technology
FDB
Mean Time Between Failures (Mtbf)
100000 h
Product Colour
Black
Cooling Type
Active
Fan Diameter
14 cm
Number Of Fans
1 fan(s)
Fan Location
Top
Operating Temperature (T-T)
0 - 40 °C
Storage Temperature (T-T)
-40 - 70 °C
Operating Relative Humidity (H-H)
20 - 90%
Storage Relative Humidity (H-H)
20 - 95%
Cables Included
AC, CPU, PCIe, Peripheral (Molex), SATA
Compliance Certificates
BSMI, CB, CCC, CE, CES, Federal Communications Commission (FCC), ICES, Low Voltage Directive (LVD), cTUVus, UKCA
Width
160 mm
Depth
150 mm
Height
86 mm
Weight
1.62 kg
