750W COUGAR Netzteil ATLAS 750W ATX / 80 Plus Bronze
Pre-Order
€60.99
VAT (19%) included
Description
80 PLUS Bronze Certified. Up to 87% efficiency power conversion to cut down your electricity bill Superior fan Curve Tuning. Advanced technology for noise minimization Single 12V DC Source. Extreme Performance for Powerful Graphics Systems PF value up to 99%. Provides clean and reliable power Compatible with the latest PC. TECHNOLOGY created for user with current and next-generation multi-core CPU platforms Support PCI express 4.0 next-generation graphics cards with 8(6+2) pin PCI-E connector FULL PROTECTIONS WITH SCP, OCP, OVP, UVP, OPP 80 PLUS Bronze Certified Up to 86% efficiency power conversion to cut down your electricity bill
Technical Specifications
SKU
KCGR BD-750
Total Power
750 W
Ac Input Voltage
100 - 240 V
Ac Input Frequency
50/60 Hz
Input Current
10 - 5 A
Maximum Input Current (@110V)
10 A
Maximum Input Current (@220V)
5 A
Combined Power (+3.3V)
140 W
Combined Power (+12V)
750 W
Combined Power (+5V)
140 W
Combined Power (-12V)
3.6 W
Combined Power (+5Vsb)
15 W
Max Output Current (+3.3V)
22 A
Max Output Current (+12V)
62.5 A
Max Output Current (+5V)
22 A
Max Output Current (-12V)
0.3 A
Max Output Current (+5Vsb)
3 A
Efficiency
86%
Power Protection Features
Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
Motherboard Power Connector
20+4 pin ATX
Motherboard Power Cable Length
55 cm
Number Of Pata Power Connectors
1
Peripheral (Molex) Power Connectors (4-Pin)
3
Peripheral (Molex) Power Cable Length
450 mm
Pci Express Power Connectors (6+2 Pin)
4
Pci Express Power Cable Length
45 cm
Cpu Power Cable Length
60 cm
Cabling Type
Non-Modular
80 Plus Certification
80 PLUS Bronze
Purpose
PC/Server
Product Colour
Black
Cooling Type
Active
Fan Diameter
12 cm
Number Of Fans
1 fan(s)
Compliance Certificates
CCC, CE, EAC, Federal Communications Commission (FCC), RoHS
Width
150 mm
Depth
140 mm
Height
86 mm
Weight
1.89 kg
Package Width
158 mm
Package Depth
187 mm
Package Height
165 mm
Package Weight
2.13 kg
Package Type
Box
