Gigabyte
850W Gigabyte P850GM | 80+ Gold Kabelmanagement
Pre-Order
€104.99
VAT (19%) included
Description
80 PLUS Gold certified Fully modular design 120mm Smart Hydraulic Bearing (HYB) Fan Main Japanese capacitors Powerful single +12V rail OVP/OPP/SCP/UVP/OCP/OTP protection Compact size
Technical Specifications
SKU
KGP-P850GM
Total Power
850 W
Ac Input Voltage
100 - 240 V
Ac Input Frequency
50 - 60 Hz
Maximum Input Current (@110V)
12 A
Maximum Input Current (@220V)
6 A
Power Factor
0.9
Power Factor Correction (Pfc) Type
Active
Combined Power (+3.3V)
120 W
Combined Power (+12V)
846 W
Combined Power (+5V)
120 W
Combined Power (-12V)
3.6 W
Combined Power (+5Vsb)
15 W
Max Output Current (+3.3V)
20 A
Max Output Current (+12V)
70.5 A
Max Output Current (+5V)
20 A
Max Output Current (-12V)
0.3 A
Max Output Current (+5Vsb)
3 A
Hold Time
16 ms
Efficiency
90%
Power Protection Features
Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
Motherboard Power Connector
20+4 pin ATX
Motherboard Power Cable Length
61 cm
Number Of Sata Power Connectors
8
Sata Power Cable Length
600, 750, 900 mm
Peripheral (Molex) Power Connectors (4-Pin)
3
Pci Express Power Connectors (6+2 Pin)
4
Pci Express Power Cable Length
75 cm
Cpu Power Cable Length
60 cm
Floppy Drive Power Connector
2
Floppy Disk Drive Cable Length
89 cm
Cabling Type
Fully-Modular
80 Plus Certification
80 PLUS Gold
Purpose
PC
Power Supply Unit (Psu) Form Factor
ATX
Atx Version
2.31
Mean Time Between Failures (Mtbf)
100000 h
Product Colour
Black
Cooling Type
Active
Fan Diameter
12 cm
Number Of Fans
1 fan(s)
Fan Location
Top
Width
150 mm
Depth
140 mm
Height
86 mm
Package Type
Box
Harmonized System (Hs) Code
84733020
