Cooler Master
850W CoolerMaster MWE V3 Gold ATX3.1
Pre-Order
€95.99
VAT (19%) included
Description
ATX 3.1 support & a durable 12V-2X6 cable 80 Plus Gold certified efficiency Silent fan performance with a zero-RPM mode Separated thermal technologies Fully modular cabling
Technical Specifications
SKU
KMPX-8503-AFAG-2EBEU
Total Power
850 W
Ac Input Voltage
100 - 240 V
Ac Input Frequency
50/60 Hz
Input Current
5 - 10 A
Power Factor Correction (Pfc) Type
Active
Combined Power (+3.3V)
120 W
Combined Power (+12V)
849.6 W
Combined Power (+5V)
120 W
Combined Power (-12V)
3.6 W
Combined Power (+5Vsb)
15 W
Max Output Current (+3.3V)
20 A
Max Output Current (+12V)
70.8 A
Max Output Current (+5V)
20 A
Max Output Current (-12V)
0.3 A
Max Output Current (+5Vsb)
3 A
Hold Time
16 ms
Efficiency
90%
Power Good Signal Delay Range
100 - 150 ms
Power Protection Features
Over current, Over power, Over voltage, Overheating, Short circuit, Surge & inrush, Under voltage
Motherboard Power Connector
24-pin ATX
Motherboard Power Cable Length
55 cm
Number Of Sata Power Connectors
6
Sata Power Cable Length
500, 620, 740, 860 mm
Peripheral (Molex) Power Connectors (4-Pin)
2
Peripheral (Molex) Power Cable Length
740, 620, 500, 860 mm
Pci Express Power Connectors (6+2 Pin)
4
Pci Express Power Connectors (12+4 Pin)
1
Pci Express Power Connectors (12+4 Pin) Cable Length
650 mm
Pci Express Power Cable Length
62 cm
Cabling Type
Fully-Modular
80 Plus Certification
80 PLUS Gold
Purpose
PC/Server
Power Supply Unit (Psu) Form Factor
ATX
Atx Version
3.1
Bearing Technology
HDB
Mean Time Between Failures (Mtbf)
100000 h
Product Colour
Black
Cooling Type
Active
Fan Diameter
12 cm
Number Of Fans
1 fan(s)
Fan Speed
0 - 2500 RPM
Operating Temperature (T-T)
0 - 40 °C
Compliance Certificates
BIS, BSMI, CCC, CE, China Compulsory Certification (CCC), EAC, Federal Communications Commission (FCC), KC, RCM, RoHS, UKCA, cTUVus
Certification
ErP 2014 Lot 3
Width
150 mm
Depth
160 mm
Height
86 mm
Weight
2.61 kg
Package Width
195 mm
Package Depth
320 mm
Package Height
125 mm
Package Weight
3 kg
Master (Outer) Cases Per Pallet
24 pc(s)
Master (Outer) Case Width
335 mm
Master (Outer) Case Length
520 mm
Master (Outer) Case Height
231 mm
Products Per Master (Outer) Case
4 pc(s)
Eps Cable Length
60 cm
