Thermaltake
1550W Thermaltake Toughpower TF1
Pre-Order
€262.99
VAT (19%) included
Description
1550 W 100 - 240 V 47 - 63 Hz Motherboard power connector: 24-pin ATX PC ATX 80 PLUS Platinum 14 cm Black
Technical Specifications
SKU
KPS-TPD-1550FNFATE-1
Total Power
1550 W
Peak Power
1860 W
Ac Input Voltage
100 - 240 V
Ac Input Frequency
47 - 63 Hz
Input Current
18 A
Power Factor Correction (Pfc) Type
Active
Combined Power (+3.3V)
120 W
Combined Power (+12V)
1549.92 W
Combined Power (+5V)
120 W
Combined Power (-12V)
6 W
Combined Power (+5Vsb)
15 W
Max Output Current (+3.3V)
22 A
Max Output Current (+12V)
129.16 A
Max Output Current (+5V)
22 A
Max Output Current (-12V)
0.5 A
Max Output Current (+5Vsb)
3 A
Hold Time
16 ms
Motherboard Power Connector
24-pin ATX
Motherboard Power Cable Length
60 cm
Number Of Sata Power Connectors
4
Sata Power Cable Length
150, 500 mm
Peripheral (Molex) Power Connectors (4-Pin)
2
Peripheral (Molex) Power Cable Length
150, 500 mm
Pci Express Power Connectors (6+2 Pin)
4
Pci Express Power Connectors (8-Pin)
4
Pci Express Power Cable Length
50 cm
Cpu Power Cable Length
7 m
Floppy Disk Drive Cable Length
15 cm
Cabling Type
Fully-Modular
80 Plus Certification
80 PLUS Platinum
Supported Motherboard Form Factors
ATX
Purpose
PC
Power Supply Unit (Psu) Form Factor
ATX
Mean Time Between Failures (Mtbf)
120000 h
Product Colour
Black
Fan Diameter
14 cm
Number Of Fans
1 fan(s)
Fan Location
Top
Operating Temperature (T-T)
0 - 50 °C
Storage Temperature (T-T)
-20 - 70 °C
Operating Relative Humidity (H-H)
20 - 90%
Storage Relative Humidity (H-H)
5 - 95%
Width
150 mm
Depth
180 mm
Height
86 mm
Weight
2.4 kg
Harmonized System (Hs) Code
84733020
