Gigabyte
650W GIGABYTE P650G ATX Netzteil, 80+ Gold, PCIe5.1, ATX3.1
Pre-Order
€64.99
VAT (19%) included
Description
ATX 3.1 and PCIe Gen 5.1 ready 80 PLUS Gold certified Main Japanese capacitors 120mm Silent Hydraulic Bearing (HYB) Fan Powerful single +12V rail OVP/OPP/SCP/UVP/OCP/OTP protection Compact design
Technical Specifications
SKU
KGP-P650G PG5
Total Power
650 W
Ac Input Voltage
100 - 240 V
Ac Input Frequency
50/60 Hz
Input Current
10 - 6 A
Maximum Input Current (@110V)
10 A
Maximum Input Current (@220V)
6 A
Power Factor Correction (Pfc) Type
Active
Combined Power (+3.3V)
90 W
Combined Power (+12V)
650 W
Combined Power (+5V)
650 W
Combined Power (-12V)
3.6 W
Combined Power (+5Vsb)
15 W
Max Output Current (+3.3V)
18 A
Max Output Current (+12V)
54.2 A
Max Output Current (+5V)
18 A
Max Output Current (-12V)
0.3 A
Max Output Current (+5Vsb)
18 A
Power Good Signal Delay Range
100 - 150 ms
Power Protection Features
Over power, Overcharge, Short circuit, Under voltage
Motherboard Power Connector
20+4 pin ATX
Motherboard Power Cable Length
60 cm
Number Of Sata Power Connectors
6
Sata Power Cable Length
120, 500 mm
Peripheral (Molex) Power Connectors (4-Pin)
3
Peripheral (Molex) Power Cable Length
150 mm
Pci Express Power Connectors (6+2 Pin)
2
Pci Express Power Cable Length
50 cm
Cpu P4 Connector (4-Pin)
1
Cpu Power Cable Length
60 cm
Cabling Type
Non-Modular
80 Plus Certification
80 PLUS Gold
Purpose
PC
Power Supply Unit (Psu) Form Factor
ATX
Atx Version
3.1
Bearing Technology
HYB
Mean Time Between Failures (Mtbf)
100000 h
Product Colour
Black
Cooling Type
Active
Fan Diameter
12 cm
Number Of Fans
1 fan(s)
Fan Location
Top
Width
140 mm
Depth
150 mm
Height
86 mm
Weight
1.76 kg
Package Width
260 mm
Package Depth
110 mm
Package Height
180 mm
Package Weight
1.92 kg
Package Type
Box
Warranty Period
5 year(s)
