Cooler Master
750W Cooler Master MWE Gold 750 V3 ATX3.1
Pre-Order
€91.99
VAT (19%) included
Description
750 W 100 - 240 V 50/60 Hz Motherboard power connector: 24-pin ATX PC ATX 80 PLUS Gold Active 12 cm 0 - 2500 RPM Black
Technical Specifications
SKU
KMPX-7503-AFAG-2EBEU
Total Power
750 W
Ac Input Voltage
100 - 240 V
Ac Input Frequency
50/60 Hz
Input Current
10 - 5 A
Power Factor Correction (Pfc) Type
Active
Combined Power (+3.3V)
120 W
Combined Power (+12V)
750 W
Combined Power (+5V)
120 W
Combined Power (-12V)
3.6 W
Combined Power (+5Vsb)
15 W
Max Output Current (+3.3V)
20 A
Max Output Current (+12V)
62.5 A
Max Output Current (+5V)
20 A
Max Output Current (-12V)
0.3 A
Max Output Current (+5Vsb)
3 A
Hold Time
16 ms
Efficiency
90%
Power Good Signal Delay Range
100 - 150 ms
Power Protection Features
Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
Motherboard Power Connector
24-pin ATX
Motherboard Power Cable Length
55 cm
Number Of Sata Power Connectors
6
Sata Power Cable Length
500, 620, 740 mm
Peripheral (Molex) Power Connectors (4-Pin)
2
Peripheral (Molex) Power Cable Length
500, 620 mm
Pci Express Power Connectors (6+2 Pin)
4
Cabling Type
Fully-Modular
80 Plus Certification
80 PLUS Gold
Purpose
PC
Power Supply Unit (Psu) Form Factor
ATX
Atx Version
3.1
Bearing Technology
HDB
Mean Time Between Failures (Mtbf)
100000 h
Product Colour
Black
Cooling Type
Active
Fan Diameter
12 cm
Number Of Fans
1 fan(s)
Fan Speed
0 - 2500 RPM
Fan Location
Top
Operating Temperature (T-T)
0 - 40 °C
Compliance Certificates
BIS, CCC, CE, EAC, Federal Communications Commission (FCC), KC, RCM, RoHS, TÜV mark, UKCA
Width
150 mm
Depth
160 mm
Height
86 mm
Weight
5.69 kg
Package Width
320 mm
Package Depth
195 mm
Package Height
125 mm
Package Weight
6.55 kg
Package Type
Box
Sustainability Certificates
ErP
