1050W COUGAR Netzteil POLAR X2 1050W ATX3.1/80 Plus Plat./Modular
Pre-Order
€186.99
VAT (19%) included
Description
Support PCI Express 5.0 Graphics Cards 12+4 Pin Connector Durable HDB Fan Fully Modular Power Supply Unit Compatible with The Lastest PC Technology 80PLUS Platinum Certified 100% Refined Japanese Capacitors Zero Noise Mode and Fan Curve Tuning Flawless Operation at 50°C
Technical Specifications
SKU
KCGR-POLAR-X2-1050
Total Power
1050 W
Ac Input Voltage
100 - 240 V
Ac Input Frequency
47 - 63 Hz
Input Current
15 - 7 A
Combined Power (+3.3V)
100 W
Combined Power (+12V)
1050 W
Combined Power (+5V)
100 W
Combined Power (-12V)
3.6 W
Combined Power (+5Vsb)
15 W
Max Output Current (+3.3V)
20 A
Max Output Current (+12V)
87.5 A
Max Output Current (+5V)
20 A
Max Output Current (-12V)
0.3 A
Max Output Current (+5Vsb)
3 A
Efficiency
90%
Power Protection Features
Overheating, Over current, Over power, Under voltage, Over voltage, Short circuit
Motherboard Power Connector
20+4 pin ATX
Motherboard Power Cable Length
65 cm
Number Of Sata Power Connectors
12
Number Of Pata Power Connectors
4
Sata Power Cable Length
120, 500 mm
Peripheral (Molex) Power Connectors (4-Pin)
4
Peripheral (Molex) Power Cable Length
120, 500 mm
Pci Express Power Connectors (6+2 Pin)
6
Pci Express Power Connectors (8-Pin)
1
Pci Express Power Connectors (12+4 Pin)
1
Pci Express Power Connectors (12+4 Pin) Cable Length
650 mm
Cpu Power Cable Length
65 cm
Cabling Type
Fully-Modular
80 Plus Certification
80 PLUS Platinum
Purpose
PC
Power Supply Unit (Psu) Form Factor
ATX
Atx Version
3.1
Noise Level
22 dB
Bearing Technology
HDB
Mean Time Between Failures (Mtbf)
100000 h
Product Colour
Silver
Cooling Type
Active
Fan Diameter
13.5 cm
Number Of Fans
1 fan(s)
Operating Temperature (T-T)
10 - 50 °C
Storage Temperature (T-T)
-40 - 70 °C
Operating Relative Humidity (H-H)
20 - 85%
Storage Relative Humidity (H-H)
5 - 95%
Compliance Certificates
EAC, TÜV mark, Federal Communications Commission (FCC), RoHS, CCC, CE
Width
150 mm
Depth
180 mm
Height
86 mm
Weight
2.09 kg
Package Width
229 mm
Package Depth
331 mm
Package Height
107 mm
Package Weight
3.59 kg
Package Type
Box
Country Of Origin
China
