Chieftec
700W Chieftec EON Series 80Plus
Pre-Order
€60.99
VAT (19%) included
Description
700 W 200 - 240 V 50 Hz Motherboard power connector: 20+4 pin ATX PC/Server ATX 80 PLUS 12 cm Black
Technical Specifications
SKU
KZPU-700S
Total Power
700 W
Ac Input Voltage
200 - 240 V
Ac Input Frequency
50 Hz
Input Current
5.5 A
Maximum Input Current (@220V)
5.5 A
Power Factor
0.9
Power Factor Correction (Pfc) Type
Active
Combined Power (-12V)
4.8 W
Max Output Current (+3.3V)
20 A
Max Output Current (+12V1)
53 A
Max Output Current (+5V)
20 A
Max Output Current (-12V)
0.4 A
Max Output Current (+5Vsb)
2.5 A
Power Protection Features
Surge and inrush, Surge protection, Short circuit
Motherboard Power Connector
20+4 pin ATX
Motherboard Power Cable Length
65 cm
Number Of Sata Power Connectors
4
Sata Power Cable Length
450, 600, 750 mm
Peripheral (Molex) Power Cable Length
450, 600, 750 mm
Pci Express Power Connectors (6+2 Pin)
2
Cabling Type
Non-Modular
80 Plus Certification
80 PLUS
Supported Motherboard Form Factors
ATX
Purpose
PC/Server
Power Supply Unit (Psu) Form Factor
ATX
Atx Version
2.3
Product Colour
Black
Fan Diameter
12 cm
Width
150 mm
Depth
140 mm
Height
86 mm
Weight
1.4 kg
Warranty Period
2 year(s)
