ASRock
ASRock Mainboard AM5D4ID-2T/BCM mini-ITX Sockel AM5 Single
Pre-Order
€613.99
VAT (19%) included
Ast2600
Description
Deep mini-ITX (6.7"x 8.2") Supports AMD EPYC™ 4004 and AMD Ryzen™ 9000/8000/7000 Series Processors 4 DIMM slots (2DPC), supports DDR5 ECC/non-ECC UDIMM 1 PCIe5.0 x16 1 OCuLink (PCIe4.0 x2) Supports 1 M.2 (PCIe4.0 x4) 2 RJ45 (10GbE) by Broadcom BCM57416 1 HDMI Remote management (IPMI)
Technical Specifications
Graphics Card
Ast2600
SKU
KAM5D4ID-2T/BCM
Processor Manufacturer
AMD
Processor Socket
Socket AM5
Compatible Processor Series
AMD EPYC 4004, AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
Supported Processor Sockets
Socket AM5
Supported Memory Types
DDR5-SDRAM
Number Of Memory Slots
4
Memory Slots Type
DIMM
Memory Voltage
1.1 V
Ecc Сompatibility
ECC & Non-ECC
Supported Memory Clock Speeds
3600, 5200 MHz
Supported Memory Clock Speed (Max)
5200 MHz
Maximum Internal Memory
192 GB
Supported Storage Drive Types
SSD
Supported Storage Drive Interfaces
M.2
Number Of Storage Drives Supported
1
Graphics Card Family
ASPEED
Usb 3.2 Gen 1 (3.1 Gen 1) Connectors
2
Number Of Com Connectors
1
Usb 3.2 Gen 1 (3.1 Gen 1) Type-A Ports Quantity
2
Ethernet Lan (Rj-45) Ports
2
Vga (D-Sub) Ports Quantity
1
Hdmi Ports Quantity
1
Ethernet Interface Type
10 Gigabit Ethernet
Lan Controller
Broadcom BCM57416
Top Wi-Fi Standard
Not available
Motherboard Chipset
KNOLL3 X300
Component For
Server
Motherboard Form Factor
mini ITX
Motherboard Chipset Family
AMD
Linux Operating Systems Supported
Ubuntu 22.04
Windows Operating Systems Supported
Windows 10 x64, Windows 11 x64
Pci Express X16 (Gen 5.X) Slots
1
Number Of M.2 (M) Slots
1
Bios Type
UEFI AMI
Bios Memory Size
256 Mbit
Acpi Version
5.1
System Management Bios (Smbios) Version
2.3
Storage Temperature (T-T)
-40 - 70 °C
Operating Temperature (T-T)
10 - 35 °C
Storage Relative Humidity (H-H)
20 - 90%
Width
170.2 mm
Depth
208.3 mm
