ASUS
Mainboard P12R-I mini-ITX Sockel 1200 Retail
Pre-Order
€337.99
VAT (19%) included
Ast2600
Description
Ideal for remote office/branch office (ROBO) use and everyday business environments Powered by eight-core Intel® Xeon E-2300-series processor with support for up to 95 W TDP Flexible expandability with six native SATA HDDs and 1 PCI Express Gen4 slot Dual Intel I210AT Gigabit Ethernet with teaming support One M.2 support to 2280 PCIe Gen4 x4 Link for faster OS booting Onboard ASUS ASMB10-iKVM with ASPEED AST2600 controller for out-of-band management
Technical Specifications
Graphics Card
Ast2600
SKU
K90SB0A70-M0UAY0
Processor Manufacturer
Intel
Processor Socket
LGA 1200 (Socket H5)
Compatible Processor Series
Intel® Pentium®, Intel Xeon E
Supported Memory Types
DDR4-SDRAM
Number Of Memory Slots
2
Memory Slots Type
DIMM
Memory Channels
Dual-channel
Supported Memory Clock Speeds
2666, 2933, 3200 MHz
Maximum Internal Memory
64 GB
Supported Memory Module Capacities
4GB, 8GB, 16GB, 32GB
Supported Storage Drive Interfaces
M.2, SATA III
Graphics Card Family
ASPEED
On-Board Graphics Card Memory
64 MB
Usb 3.2 Gen 1 (3.1 Gen 1) Connectors
1
Number Of Sata Iii Connectors
6
Number Of Chassis Fan Connectors
2
Serial Port Headers
1
Usb 3.2 Gen 1 (3.1 Gen 1) Type-A Ports Quantity
4
Ethernet Lan (Rj-45) Ports
3
Vga (D-Sub) Ports Quantity
1
Number Of Sas Ports
2
Lan Controller
Intel® I210-AT
Top Wi-Fi Standard
Not available
Motherboard Chipset
Intel C252
Component For
Server
Motherboard Form Factor
ATX
Motherboard Chipset Family
Intel
Pci Express X16 Slots
1
Number Of M.2 (M) Slots
1
Storage Temperature (T-T)
-40 - 70 °C
Operating Temperature (T-T)
10 - 50 °C
Storage Relative Humidity (H-H)
20 - 90%
Harmonized System (Hs) Code
84733020
Package Width
311 mm
Package Depth
281 mm
Package Height
78 mm
Package Weight
1.2 kg
Width
170 mm
Depth
170 mm
Weight
500 g
