ASRock
1700 ASROCK H610M-HDV/M.2 R2.0 mATX D4
Pre-Order
€77.99
VAT (19%) included
Intel Iris Xe Graphics
Description
Supports 14th, 13th & 12th Gen Intel® Core™ Processors (LGA1700) 6+1+1 Phase Power Design Supports DDR4 3200MHz 1 PCIe 4.0 x16, 1 PCIe 3.0 x1 Graphics Output Options: HDMI, DisplayPort, D-Sub Realtek ALC897 7.1 CH HD Audio Codec 1 Ultra M.2 (PCIe Gen3 x4) 4 USB 3.2 Gen1 (2 Rear, 2 Front) 6 USB 2.0 (4 Rear, 2 Front) Realtek Gigabit LAN
Technical Specifications
Graphics Card
Intel Iris Xe Graphics
SKU
K90-MXBJH0-A0UAYZ
Processor Manufacturer
Intel
Processor Socket
LGA 1700
Compatible Processor Series
Intel® Celeron® G, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold
Supported Processor Sockets
LGA 1700
Supported Memory Types
DDR4-SDRAM
Number Of Memory Slots
2
Memory Slots Type
DIMM
Memory Channels
Dual-channel
Ecc Сompatibility
Non-ECC
Supported Memory Clock Speed (Max)
3200 MHz
Maximum Internal Memory
64 GB
Supported Storage Drive Interfaces
M.2
Number Of Storage Drives Supported
5
Graphics Card Family
Intel
Maximum Resolution
7680 x 4320 pixels
Usb 2.0 Connectors
1
Usb 3.2 Gen 1 (3.1 Gen 1) Connectors
2
Number Of Sata Iii Connectors
4
Number Of Chassis Fan Connectors
1
Usb 2.0 Ports Quantity
4
Usb 3.2 Gen 1 (3.1 Gen 1) Type-A Ports Quantity
2
Ethernet Lan (Rj-45) Ports
1
Ps/2 Ports Quantity
1
Vga (D-Sub) Ports Quantity
1
Hdmi Ports Quantity
1
Hdmi Version
2.1
Displayports Quantity
1
Displayport Version
1.4
Headphone Outputs
1
Usb Connector Type
USB Type-A
Ethernet Interface Type
Gigabit Ethernet
Lan Controller
Realtek RTL8111H
Top Wi-Fi Standard
Not available
Motherboard Chipset
Intel H610
Audio Chip
Realtek ALC897
Audio Output Channels
7.1 channels
Product Colour
Black, Grey, Silver
Pc Health Monitoring
CPU, Fan, Voltage, Water cooling
Component For
PC
Motherboard Form Factor
micro ATX
Motherboard Chipset Family
Intel
Windows Operating Systems Supported
Windows 10 x64, Windows 11 x64
Pci Express X1 (Gen 3.X) Slots
1
Pci Express X16 (Gen 4.X) Slots
1
Number Of M.2 (M) Slots
1
Bios Type
UEFI AMI
Bios Memory Size
128 Mbit
Acpi Version
6.0
System Management Bios (Smbios) Version
2.7
Width
220 mm
Depth
193 mm
Cables Included
SATA
Sustainability Certificates
ErP
Compliance Certificates
CE, EuP, Federal Communications Commission (FCC)
