ASRock
ASRock Mainboard GNR2D16-2T EEB like dual Sockel 4710 Single
Pre-Order
€1340.99
VAT (19%) included
Ast2600
Description
EEB like (12.24" x 13.3") Supports Intel® Xeon® 6700P-series, 6500P-series, and 6700E-series processors 8+8 DIMM slots (1DPC); supports DDR5 RDIMM, MRDIMM 5 PCIe5.0 / CXL2.0 x16 1 PCIe5.0 / CXL2.0 x8 1 MCIO (PCIe5.0 / CXL2.0 x8) Supports 2 M.2 (PCIe5.0 x2) Up to 8 SATA 6Gb/s 2 RJ45 (10GbE) by Intel X710-AT2 Remote management (IPMI)
Technical Specifications
Graphics Card
Ast2600
SKU
KGNR2D16-2T
Processor Manufacturer
Intel
Processor Socket
LGA 4710 (Socket E2)
Compatible Processor Series
Intel Xeon 6300
Maximum Number Of Smp Processors
2
Supported Memory Types
DDR5-SDRAM
Number Of Memory Slots
16
Memory Voltage
1.1 V
Supported Memory Clock Speeds
6400, 8000 MHz
Maximum Internal Memory
128 GB
Supported Storage Drive Interfaces
SATA III
Graphics Card Family
ASPEED
Usb 3.2 Gen 1 (3.1 Gen 1) Connectors
2
Number Of Sata Iii Connectors
8
Number Of Com Connectors
1
Usb 3.2 Gen 1 (3.1 Gen 1) Type-A Ports Quantity
2
Ethernet Lan (Rj-45) Ports
2
Vga (D-Sub) Ports Quantity
1
Ethernet Interface Type
10 Gigabit Ethernet
Lan Controller
Intel X710-AT2
Motherboard Chipset
Intel SoC
Component For
Server
Motherboard Form Factor
EEB
Motherboard Chipset Family
Intel
Pci Express X8 (Gen 5.X) Slots
1
Pci Express X16 (Gen 5.X) Slots
5
Bios Type
UEFI AMI
Bios Memory Size
512 Mbit
Acpi Version
4.0
System Management Bios (Smbios) Version
3.4
Storage Temperature (T-T)
-40 - 70 °C
Operating Temperature (T-T)
10 - 35 °C
Operating Relative Humidity (H-H)
20 - 90%
Width
310.9 mm
Depth
337.8 mm
