ASUS
MB ASUS PRO WS Z890-ACE SE (Intel.1851.DDR5.mATX)
Pre-Order
€624.99
VAT (19%) included
Description
Ready for advanced AI PCs: Designed for the future of AI computing, with the power and connectivity needed for demanding AI applications Intel LGA1851 socket: Ready for Intel® Core™ Ultra 9, 7, and 5 desktop processors Robust performance: 16+2+1+2 teamed power stages, ProCool II power connectors, high-quality alloy chokes and durable capacitors Future-proofed connectivity: Thunderbolt™ 4, 10Gb & 2.5Gb Ethernet, two PCIe® 5.0 PCIe slots with full support for next-gen graphics cards, one PCIe 5.0 M.2 and three PCIe 4.0 M.2 slots and a USB 20Gbps front-panel header Exclusive AI and overclocking technologies: AI Overclocking, AI Cooling II, AI Advisor and NPU boost DIY-friendly design: PCIe Slot Q-Release Slim with SafeSlot, M.2 Q-Latch, BIOS FlashBack™, Q-Connector Server-grade IPMI remote management and onboard BMC: Hardware- and software-level management with a dedicated LAN port link to an onboard AST2600 BMC controller, plus ASUS Control Center Express software for real-time monitoring and management
Technical Specifications
SKU
K90MB1JC0-M0EAY0
Processor Manufacturer
Intel
Processor Socket
LGA 1851 (Socket V1)
Compatible Processor Series
Intel Core Ultra (Series 2)
Supported Processor Sockets
LGA 1851
Supported Memory Types
DDR5-SDRAM
Number Of Memory Slots
4
Memory Slots Type
DIMM
Memory Channels
Dual-channel
Ecc Сompatibility
Non-ECC
Supported Memory Clock Speed (Max)
9066 MHz
Maximum Internal Memory
256 GB
Supported Storage Drive Types
HDD & SSD
Supported Storage Drive Interfaces
M.2, PCI Express 5.0, SATA III
Number Of Hdds Supported
4
Number Of Storage Drives Supported
8
Raid Levels
0, 1, 5, 10
Parallel Processing Technology Support
Not supported
Usb 2.0 Connectors
2
Usb 3.2 Gen 1 (3.1 Gen 1) Connectors
1
Usb 3.2 Gen 2X2 Connectors
1
Number Of Sata Iii Connectors
4
Number Of Cpu Fan Connectors
1
Number Of Chassis Fan Connectors
5
Number Of Eps Power Connectors (8-Pin)
2
Number Of Com Connectors
1
Thunderbolt Headers
1
Integrated Sas Ports
1
Number Of Water Pump Connectors
1
Number Of Temperature Sensor Headers
1
Usb 3.2 Gen 2 (3.1 Gen 2) Type-A Ports Quantity
6
Usb 3.2 Gen 2X2 Type-C Ports Quantity
1
Ethernet Lan (Rj-45) Ports
3
Hdmi Ports Quantity
1
Headphone Outputs
1
Thunderbolt Ports Quantity
1
Ethernet Interface Type
2.5 Gigabit Ethernet, 10 Gigabit Ethernet, Gigabit Ethernet
Top Wi-Fi Standard
Not available
Motherboard Chipset
Intel Z890
Audio Chip
Realtek ALC1220P
Audio Output Channels
7.1 channels
Product Colour
Black
Component For
PC
Motherboard Form Factor
ATX
Motherboard Chipset Family
Intel
Cooling Type
Passive
Power Source Type
ATX
Windows Operating Systems Supported
Windows 10 x64, Windows 11
Pci Express X16 (Gen 4.X) Slots
1
Pci Express X16 (Gen 5.X) Slots
2
Number Of M.2 (M) Slots
4
1St M.2 Largest Key Size
2280
1St M.2 Highest Pci Express Generation
5.0
2Nd M.2 Largest Key Size
2280
2Nd M.2 Highest Pci Express Generation
4.0
3Rd M.2 Largest Key Size
2280
3Rd M.2 Highest Pci Express Generation
4.0
4Th M.2 Largest Key Size
2280
4Th M.2 Highest Pci Express Generation
4.0
Bios Type
UEFI AMI
Bios Memory Size
256 Mbit
Package Width
338.1 mm
Package Depth
256 mm
Package Height
50.8 mm
Package Weight
1.43 kg
Width
305 mm
Depth
244 mm
Cables Included
SATA
