Gigabyte
Gigabyte X870E AORUS XTREME X3D AI TOP (AM5) (D)
Pre-Order
€1202.99
VAT (19%) included
Description
X3D Turbo Mode 2.0: Incredible X3D performance unleashed by AI AMD Socket AM5: Supports AMD Ryzen 9000 / 8000 / 7000 Series Processors CPU Thermal Matrix: achieve extreme cooling across the VRM & DDR Zone Digital twin 24+2+2 phases VRM solution Dual Channel DDR5: DDR5 OC up to 9000MT/s, 4*DIMMs with AMD EXPO Memory Module Support Ultra-Fast Storage: 5*M.2 slots, including PCIe 5.0 x4 Fast Networking: Dual 10GbE LAN & Wi-Fi 7 with directional Ultra-high gain antenna Extended Connectivity: HDMI, Dual USB4 Type-C with DP-Alt, Front QC-USB 65W PCB Thermal Plate: 14% thermal improvement and reinforced motherboard stability 5" LCD Edge View: AORUS Real time Dynamic visuals with edge-crafted aesthetics, delivering instant system insight
Technical Specifications
SKU
KX870E A XTR X AI TOP
Processor Manufacturer
AMD
Processor Socket
Socket AM5
Compatible Processor Series
AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
Supported Processor Sockets
Socket AM5
Supported Memory Types
DDR5-SDRAM
Number Of Memory Slots
4
Memory Slots Type
DIMM
Memory Channels
Dual-channel
Ecc Сompatibility
Non-ECC
Supported Memory Clock Speeds
9000, 8800, 8600, 8400, 8000, 7800, 7600, 7200, 7000, 6800, 6600, 6400, 6200, 6000, 5600, 5200, 4800, 4400 MHz
Supported Memory Clock Speed (Max)
9000 MHz
Maximum Internal Memory
256 GB
Maximum Internal Memory Per Slot
64 GB
Supported Storage Drive Types
HDD & SSD
Supported Storage Drive Interfaces
M.2, SATA III
Number Of Hdds Supported
2
Number Of Storage Drives Supported
7
Raid Levels
0, 1, 5, 10
Parallel Processing Technology Support
Not supported
Maximum Resolution
4096 x 2160 pixels
Hdcp Version
2.3
Directx Version
12.0
Usb 2.0 Connectors
1
Usb 3.2 Gen 1 (3.1 Gen 1) Connectors
2
Usb 3.2 Gen 2 (3.1 Gen 2) Connectors
1
Usb 3.2 Gen 2X2 Connectors
1
Number Of Sata Iii Connectors
2
Number Of Cpu Fan Connectors
2
Number Of Chassis Fan Connectors
3
Number Of Eps Power Connectors (8-Pin)
2
Number Of Water Pump Connectors
3
Number Of Temperature Sensor Headers
2
Number Of Rgb Led Pin Headers
1
Usb 3.2 Gen 2 (3.1 Gen 2) Type-A Ports Quantity
8
Usb 3.2 Gen 2 (3.1 Gen 2) Type-C Ports Quantity
1
Usb 3.2 Gen 2X2 Type-C Ports Quantity
1
Usb4 Gen 2X2 Ports Quantity
2
Ethernet Lan (Rj-45) Ports
2
Hdmi Ports Quantity
1
Hdmi Version
2.1
Displayport Version
1.4
Digital Audio Optical Out
1
Wifi-Ap Antenna Jack
2
Ethernet Interface Type
10 Gigabit Ethernet
Lan Controller
Realtek RTL8127
Top Wi-Fi Standard
Wi-Fi 7 (802.11be)
Wi-Fi Standards
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
Wlan Controller Model
MediaTek MT7927
Bluetooth Version
5.4
Motherboard Chipset
AMD X870E
Audio Chip
1 ESS ES9280AC + 2 ESS ES9080
Audio Output Channels
7.1 channels
Product Colour
Black
Pc Health Monitoring
Fan, Temperature, Voltage, Water cooling
Component For
PC
Motherboard Form Factor
Extended ATX
Motherboard Chipset Family
AMD
Cooling Type
Passive
Power Source Type
ATX
Windows Operating Systems Supported
Windows 11 x64
Pci Express X16 (Gen 4.X) Slots
1
Pci Express X16 (Gen 5.X) Slots
2
Number Of M.2 (M) Slots
5
1St M.2 Largest Key Size
2580
1St M.2 Highest Pci Express Generation
5.0
2Nd M.2 Largest Key Size
22110
2Nd M.2 Highest Pci Express Generation
5.0
3Rd M.2 Largest Key Size
22110
3Rd M.2 Highest Pci Express Generation
4.0
4Th M.2 Largest Key Size
22110
4Th M.2 Highest Pci Express Generation
4.0
5Th M.2 Largest Key Size
2280
5Th M.2 Highest Pci Express Generation
4.0
Bios Type
UEFI AMI
Bios Memory Size
512 Mbit
Acpi Version
5.0
Desktop Management Interface (Dmi) Version
2.7
System Management Bios (Smbios) Version
2.7
Country Of Origin
Taiwan
Products Per Shipping (Inner) Case
1 pc(s)
Battery Weight
3 g
Lithium Weight Per Battery
0.07 g
Number Of Battery Cells
1
Battery Capacity
220 mAh
Battery Technology
Lithium-Manganese Dioxide (LiMnO2)
Battery Type
CR2032
Package Width
387 mm
Package Depth
387 mm
Package Height
167 mm
Package Weight
11.2 kg
Width
305 mm
Depth
285 mm
Height
35 mm
Bundled Software
Norton® Internet Security (OEM version)
Weight
8.02 kg
Warranty Period
3 year(s)
