MSI
MSI B550 Gaming WiFi6E (B550,AM4,ATX,DDR4)
Pre-Order
Usually ready in 3-5 business days
+ €30 Supplier Shipping
€144.99
VAT (19%) included
Description
Supports AMD Ryzen™ 5000 Series, 5000 G-Series, 4000 G-Series, and 3000 Series processors Supports DDR4 Memory, up to 4800+MHz (OC) Lightning Fast Game experience: PCIe 4.0 slot, Lightning Gen 4 x4 M.2, Front USB Type-C EZ DIY: EZ Debug LED and EZ Mounting Wi-Fi 6E Solution: the ideal solution for professional and multimedia use, delivering secure, stable, and high-speed networking and data transmission Audio Boost: Reward your ears with studio-grade sound quality for the most immersive gaming experience MSI Center: A brand-new software which integrates all MSI exclusive tools with user-friendly user interface
Technical Specifications
SKU
K7C56-092R
Processor Manufacturer
AMD
Processor Socket
Socket AM4
Compatible Processor Series
AMD Ryzen 5000 Series, AMD Ryzen 3000 Series, AMD Ryzen 4000 Series
Supported Processor Sockets
Socket AM4
Supported Memory Types
DDR4-SDRAM
Number Of Memory Slots
4000
Memory Slots Type
DIMM
Memory Channels
Dual-channel
Ecc Сompatibility
Non-ECC
Supported Memory Clock Speeds
2667, 2800, 2933, 3000, 3066, 3200, 3466, 3600, 3733, 3866, 4000, 4133, 4266, 4400, 4533, 4600, 4733, 4800, 4866 MHz
Supported Memory Clock Speed (Max)
4800 MHz
Maximum Internal Memory
128 GB
Supported Storage Drive Types
HDD & SSD
Supported Storage Drive Interfaces
M.2, PCI Express 4.0, PCI Express 3.0, SATA
Number Of Storage Drives Supported
2
Usb 2.0 Connectors
4000
Usb 3.2 Gen 1 (3.1 Gen 1) Connectors
3
Usb 3.2 Gen 2 (3.1 Gen 2) Connectors
2
Number Of Sata Iii Connectors
6
Number Of Sata Connectors
6
Total Number Of Sata Connectors
6
Usb 2.0 Ports Quantity
8
Usb 3.2 Gen 2 (3.1 Gen 2) Type-A Ports Quantity
1
Usb 3.2 Gen 2 (3.1 Gen 2) Type-C Ports Quantity
1
Ethernet Lan (Rj-45) Ports
1
Hdmi Ports Quantity
1
Hdmi Version
1.4
Displayports Quantity
1
Displayport Version
1.2
Ethernet Interface Type
Gigabit Ethernet
Lan Controller
Realtek 8111H
Top Wi-Fi Standard
Wi-Fi 6E (802.11ax)
Wi-Fi Standards
Wi-Fi 6 (802.11ax)
Bluetooth Version
5.3
Motherboard Chipset
AMD B550
Audio Chip
Realtek ALC897
Audio Output Channels
7.1 channels
Component For
PC
Motherboard Chipset Family
AMD
Pci Express X1 (Gen 3.X) Slots
1
Pci Express X1 (Gen 4.X) Slots
1
Pci Express X16 Slots
1
Pci Express X16 (Gen 3.X) Slots
1
Pci Express X16 (Gen 4.X) Slots
1
Number Of M.2 (M) Slots
2
1St M.2 Largest Key Size
2280
1St M.2 Highest Pci Express Generation
4.0
2Nd M.2 Largest Key Size
2280
2Nd M.2 Highest Pci Express Generation
3.0
Bios Type
UEFI AMI
Bios Memory Size
256 Mbit
Acpi Version
6.0
System Management Bios (Smbios) Version
2.8
Processor Socket
AM4
Supported Memory Types
DDR4
