ASROCK B760M-H2/M.2 (1700) (D)
Pre-Order
€89.99
VAT (19%) included
Description
Supports 14th, 13th & 12th Gen Intel® Core™ Processors (LGA1700) 5+1+1 Power Phase 2 x DDR5 DIMMs Supports Dual Channel, up to 7200+ (OC) 1 PCIe 4.0 x16, 2 PCIe 3.0 x1, 1 M.2 Key E for WiFi Graphics Output Options: 2 HDMI Realtek ALC897 7.1 CH HD Audio Codec 4 SATA3, 2 Hyper M.2 (PCIe Gen4 x4) 6 USB 3.2 Gen1 Type-A (4 Rear, 2 Front) 6 USB 2.0 (2 Rear, 4 Front) Dragon 2.5G LAN Supports ASRock Auto Driver Installer
Technical Specifications
SKU
K90-MXBN00-A0UAYZ
Processor Manufacturer
Intel
Processor Socket
LGA 1700
Compatible Processor Series
Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9
Maximum Number Of Smp Processors
1
Supported Processor Sockets
LGA 1700
Maximum Internal Memory Supported By Processor
128 GB
Supported Memory Types
DDR5-SDRAM
Number Of Memory Slots
2
Memory Slots Type
DIMM
Memory Channels
Dual-channel
Ecc Сompatibility
Non-ECC
Supported Memory Clock Speeds
5600, 6800, 7200 MHz
Supported Memory Clock Speed (Max)
7200 MHz
Maximum Internal Memory
128 GB
Supported Storage Drive Interfaces
M.2, SATA III
Number Of Hdds Supported
6
Number Of Storage Drives Supported
4
Raid Levels
0, 1, 5, 10
Parallel Processing Technology Support
Not supported
Usb 2.0 Connectors
4
Usb 3.2 Gen 1 (3.1 Gen 1) Connectors
2
Number Of Sata Iii Connectors
4
Total Number Of Sata Connectors
4
Usb 2.0 Ports Quantity
2
Usb 3.2 Gen 1 (3.1 Gen 1) Type-A Ports Quantity
4
Usb 3.2 Gen 1 (3.1 Gen 1) Type-C Ports Quantity
1
Ethernet Lan (Rj-45) Ports
1
Ps/2 Ports Quantity
1
Hdmi Ports Quantity
2
Hdmi Version
2.1
Ethernet Interface Type
2.5 Gigabit Ethernet
Top Wi-Fi Standard
Not available
Motherboard Chipset
Intel B760
Audio Chip
Realtek ALC897
Audio Output Channels
7.1 channels
Component For
PC
Motherboard Form Factor
micro ATX
Motherboard Chipset Family
Intel
Windows Operating Systems Supported
Windows 10 x64, Windows 11 x64
Certification
- FCC, CE - ErP/EuP ready (ErP/EuP ready power supply is required)
Pci Express X1 (Gen 3.X) Slots
2
Pci Express X16 (Gen 4.X) Slots
1
Number Of M.2 (M) Slots
2
Bios Type
UEFI AMI
Bios Memory Size
128 Mbit
Width
244 mm
Depth
201 mm
Cables Included
SATA
