Gigabyte
TRX50 AI TOP (sTR5) (D)
Pre-Order
€1001.99
VAT (19%) included
Description
Training your own AI on your desk Socket sTR5: Supports AMD Ryzen Threadripper PRO 7000 series/ Ryzen Threadripper 7000 series Processors Breakthrough Performance：16+8+4 Phases Digital VRM Solution 8 Channel DDR5：8SMD ECC R-DIMMs with Maxmium 2TB capacity Reinforced Overall Thermal：VRM Thermal Armor Advanced & M.2 Thermal Guard Ultimate Scalibility: 4PCIe 5.0 x16 slots for Multi-GPU and 4*PCIe 5.0 x4 M.2 slots Next-gen Connectivity: Dual USB4 Type-C ports Blazing Fast Networks: Dual 10GbE LAN, Wi-Fi 7 with Ultra-high gain directional antenna & WIFI EZ-Plug PCIe UD Slot X：PCIe 5.0 x16 slot with 10X strength for graphics card EZ-Latch Click：M.2 heatsinks with screwless design EZ-Latch Plus：M.2 slots with quick release design Hi-Fi Audio with DTS:X Ultra：ALC4080+ALC897 CODEC
Technical Specifications
SKU
KTRX50 AI TOP-2B
Processor Manufacturer
AMD
Processor Socket
Socket sTR5
Compatible Processor Series
AMD Ryzen Threadripper 7000 Series, AMD Ryzen Threadripper PRO 7000 WX-Series
Supported Processor Sockets
Socket sTR5
Supported Memory Types
DDR5-SDRAM
Number Of Memory Slots
8
Memory Slots Type
DIMM
Memory Channels
Quad-channel
Ecc Сompatibility
ECC
Supported Memory Clock Speed (Max)
5200 MHz
Maximum Internal Memory
2 TB
Supported Storage Drive Types
HDD & SSD
Supported Storage Drive Interfaces
M.2, PCI Express 5.0, SATA III
Number Of Hdds Supported
4
Number Of Storage Drives Supported
8
Raid Levels
0, 1, 10
Parallel Processing Technology Support
Not supported
Directx Version
12.0
Usb 2.0 Connectors
2
Usb 3.2 Gen 1 (3.1 Gen 1) Connectors
2
Usb 3.2 Gen 2X2 Connectors
1
Number Of Sata Iii Connectors
4
Number Of Cpu Fan Connectors
2
Number Of Chassis Fan Connectors
6
Number Of Eps Power Connectors (8-Pin)
2
Number Of Water Pump Connectors
5
Number Of Temperature Sensor Headers
2
Number Of Noise Detection Headers
1
Number Of Rgb Led Pin Headers
4
Usb 3.2 Gen 2 (3.1 Gen 2) Type-A Ports Quantity
6
Usb4 Gen 3X2 Ports Quantity
2
Ethernet Lan (Rj-45) Ports
2
Displayports Quantity
1
Headphone Outputs
1
Wifi-Ap Antenna Jack
2
Ethernet Interface Type
2.5 Gigabit Ethernet, 5 Gigabit Ethernet, 10 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet
Lan Controller
Marvell AQtion AQC113C
Top Wi-Fi Standard
Wi-Fi 7 (802.11be)
Wi-Fi Standards
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
Wlan Controller Model
Qualcomm QCNCM865
Bluetooth Version
5.3
Motherboard Chipset
AMD TRX50
Audio Chip
Realtek ALC897 / Realtek ALC4080
Audio Output Channels
2.0 channels
Product Colour
Black
Pc Health Monitoring
Fan, Temperature, Voltage, Water cooling
Component For
PC
Motherboard Form Factor
Extended ATX
Motherboard Chipset Family
AMD
Cooling Type
Active
Power Source Type
ATX
Linux Operating Systems Supported
Ubuntu 24.04 LTS
Windows Operating Systems Supported
Windows 11 x64
Pci Express X16 (Gen 5.X) Slots
4
Number Of M.2 (M) Slots
4
1St M.2 Largest Key Size
2280
1St M.2 Highest Pci Express Generation
5.0
2Nd M.2 Largest Key Size
2280
2Nd M.2 Highest Pci Express Generation
5.0
3Rd M.2 Largest Key Size
2280
3Rd M.2 Highest Pci Express Generation
5.0
4Th M.2 Largest Key Size
2280
4Th M.2 Highest Pci Express Generation
5.0
Bios Type
UEFI AMI
Bios Memory Size
256 Mbit
Acpi Version
5.0
Desktop Management Interface (Dmi) Version
2.7
System Management Bios (Smbios) Version
2.7
Country Of Origin
China
Products Per Shipping (Inner) Case
1 pc(s)
Battery Weight
3 g
Lithium Weight Per Battery
0.07 g
Number Of Battery Cells
1
Battery Technology
Lithium-Manganese Dioxide (LiMnO2)
Battery Type
CR2032
Package Width
379 mm
Package Depth
397 mm
Package Height
105 mm
Package Weight
6.47 kg
Width
305 mm
Depth
330 mm
Height
35 mm
Bundled Software
Norton® Internet Security (OEM version) LAN bandwidth management software
Warranty Period
3 year(s)
