Intel
Intel S1151 CORE i5 9500 TRAY 6x3,0 65W GEN9
Pre-Order
€201.99
VAT (19%) included
Description
Intel® Core™ i5 i5-9500 3 GHz 9 MB Smart Cache LGA 1151 (Socket H4) Processor cores: 6 14 nm 64-bit 65 W Maximum internal memory supported by processor: 128 GB DDR4-SDRAM On-board graphics card Intel® UHD Graphics 630 Tray
Technical Specifications
SKU
KCM8068403362610
Processor Manufacturer
Intel
Processor Generation
9th gen Intel® Core™ i5
Processor Model
i5-9500
Processor Base Frequency
3 GHz
Processor Family
Intel® Core™ i5
Processor Cores
6
Processor Socket
LGA 1151 (Socket H4)
Component For
PC
Processor Lithography
14 nm
Processor Series
9th Generation Intel Core i5 Processors
Processor Threads
6
System Bus Rate
8 GT/s
Processor Operating Modes
64-bit
Processor Boost Frequency
4.4 GHz
Processor Cache
9 MB
Processor Cache Type
Smart Cache
Thermal Design Power (Tdp)
65 W
Package Type
Tray
Generation
9th Generation
Memory Bandwidth Supported By Processor (Max)
41.6 GB/s
Processor Codename
Coffee Lake
Processor Ark Id
134895
Maximum Internal Memory Supported By Processor
128 GB
Memory Types Supported By Processor
DDR4-SDRAM
Memory Clock Speeds Supported By Processor
2666 MHz
Memory Channels
Dual-channel
On-Board Graphics Card Model
Intel® UHD Graphics 630
Maximum On-Board Graphics Card Memory
64 GB
On-Board Graphics Card Outputs Supported
DisplayPort, Embedded DisplayPort (eDP), HDMI
On-Board Graphics Card Base Frequency
350 MHz
On-Board Graphics Card Dynamic Frequency (Max)
1100 MHz
Number Of Displays Supported (On-Board Graphics)
3
On-Board Graphics Card Directx Version
12.0
On-Board Graphics Card Opengl Version
4.5
On-Board Graphics Card Maximum Resolution (Displayport)
4096 x 2304 pixels
On-Board Graphics Card Maximum Resolution (Edp - Integrated Flat Panel)
4096 x 2304 pixels
On-Board Graphics Card Maximum Resolution (Hdmi)
4096 x 2304 pixels
On-Board Graphics Card Refresh Rate At Maximum Resolution (Displayport)
60 Hz
On-Board Graphics Card Refresh Rate At Maximum Resolution (Edp - Integrated Flat Panel)
60 Hz
On-Board Graphics Card Refresh Rate At Maximum Resolution (Hdmi)
24 Hz
On-Board Graphics Card Id
0x3E92
Discrete Graphics Card Model
Not available
Market Segment
Desktop
Maximum Number Of Pci Express Lanes
16
Pci Express Slots Version
3.0
Pci Express Configurations
1x16, 2x8, 1x8+2x4
Supported Instruction Sets
SSE4.1, SSE4.2, AVX 2.0
Scalability
1S
Cpu Configuration (Max)
1
Thermal Solution Specification
PCG 2015C
Pci Express Cem Revision
3.0
Export Control Classification Number (Eccn)
5A992C
Commodity Classification Automated Tracking System (Ccats)
G077159
Intel® Turbo Boost Technology
2.0
Intel® Turbo Boost Technology 2.0 Frequency
4.4 GHz
Tjunction
100 °C
Launch Date
Q2'19
Maximum Resolution & Refresh Rate (Displayport)
4096 x 2304@60Hz
Product Type
Processor
Status
Launched
Maximum Memory
128 GB
Supported Memory Types
DDR4-SDRAM
Bus Speed
8 GT/s
Maximum Graphics Card Memory
64 GB
Processor Id
0x3E92
Harmonized System (Hs) Code
8542310001
Package Width
70 mm
Package Depth
116 mm
Package Height
101 mm
Package Weight
338 g
Processor Package Size
37.5 x 37.5 mm
Maximum Internal Memory
128 GB
