Intel
Intel S1700 CORE i9 12900 BOX 16x2,4 65W GEN12
Pre-Order
€498.99
VAT (19%) included
Description
Intel® Core™ i9 i9-12900 30 MB Smart Cache LGA 1700 Processor cores: 16 64-bit Maximum internal memory supported by processor: 128 GB DDR4-SDRAM, DDR5-SDRAM On-board graphics card Intel UHD Graphics 770 Box Cooler included
Technical Specifications
SKU
KBX8071512900
Processor Manufacturer
Intel
Processor Generation
12th gen Intel® Core™ i9
Processor Model
i9-12900
Processor Family
Intel® Core™ i9
Processor Cores
16
Processor Socket
LGA 1700
Processor Threads
24
Processor Operating Modes
64-bit
Performance Cores
8
Efficient Cores
8
Processor Boost Frequency
5.1 GHz
Performance-Core Boost Frequency
5 GHz
Performance-Core Base Frequency
2.4 GHz
Efficient-Core Boost Frequency
3.8 GHz
Efficient-Core Base Frequency
1.8 GHz
Processor Cache
30 MB
Processor Cache Type
Smart Cache
Package Type
Box
Processor Base Power
65 W
Maximum Turbo Power
202 W
Stepping
C0
Bus Type
DMI4
Maximum Number Of Dmi Lanes
8
Memory Bandwidth Supported By Processor (Max)
76.8 GB/s
Processor Codename
Alder Lake
Processor Ark Id
134597
Maximum Internal Memory Supported By Processor
128 GB
Memory Types Supported By Processor
DDR4-SDRAM, DDR5-SDRAM
Memory Channels
Dual-channel
Memory Bandwidth (Max)
76.8 GB/s
On-Board Graphics Card Model
Intel UHD Graphics 770
On-Board Graphics Card Outputs Supported
Embedded DisplayPort (eDP), Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, DisplayPort 1.4, HDMI 2.1
On-Board Graphics Card Base Frequency
300 MHz
On-Board Graphics Card Dynamic Frequency (Max)
1.55 MHz
Number Of Displays Supported (On-Board Graphics)
4
On-Board Graphics Card Directx Version
12.0
On-Board Graphics Card Opengl Version
4.5
On-Board Graphics Card Maximum Resolution (Displayport)
7680 x 4320 pixels
On-Board Graphics Card Maximum Resolution (Edp - Integrated Flat Panel)
5120 x 3200 pixels
On-Board Graphics Card Maximum Resolution (Hdmi)
4096 x 2160 pixels
On-Board Graphics Card Refresh Rate At Maximum Resolution (Displayport)
60 Hz
On-Board Graphics Card Refresh Rate At Maximum Resolution (Edp - Integrated Flat Panel)
120 Hz
On-Board Graphics Card Refresh Rate At Maximum Resolution (Hdmi)
60 Hz
On-Board Graphics Card Id
0x4680
Discrete Graphics Card Model
Not available
Number Of Execution Units
32
Multi-Format Codec Engines
2
Market Segment
Desktop
Use Conditions
PC/Client/Tablet, Workstation
Maximum Number Of Pci Express Lanes
20
Pci Express Slots Version
5.0, 4.0
Pci Express Configurations
1x16+1x4, 2x8+1x4
Supported Instruction Sets
SSE4.1, SSE4.2, AVX 2.0
Scalability
1S
Cpu Configuration (Max)
1
Thermal Solution Specification
PCG 2020C
Direct Media Interface (Dmi) Revision
4.0
Export Control Classification Number (Eccn)
5A992.C
Commodity Classification Automated Tracking System (Ccats)
G167599
Intel® Turbo Boost Technology
2.0
Intel® Turbo Boost Max Technology 3.0 Frequency
5.1 GHz
Maximum Operating Temperature
100 °C
Tjunction
100 °C
Target Market
Gaming, Content Creation
Opencl Version
3.0
Launch Date
Q1'22
Status
Launched
Harmonized System (Hs) Code
85423119
Processor Package Size
45 x 37.5 mm
L2 Cache
14336 KB
Maximum Internal Memory
128 GB
Graphics Output
eDP 1.4b, DP 1.4a, HDMI 2.1
